| Refer Technical information of Electrical , Mechanical ,Hydraulic and recommendation chart under Downloads menu before selection of Pump. Else fillup check list for pumps under downloads menu. |
CONVENTIONAL & MONOBLOCK COOLANT PUMP RV25¦RV250 |
| CONSTRUCTION |
OPTIONS |
APPLICATION |
Stem |
C.I. |
Stem |
Gunmetal/S.S |
Types of Fluids |
Water
Cooling Emulsion
Cooling/Cutting Oils |
Impeller |
Velox553/AL |
Impeller |
Gunmetal/CI/S.S |
Kinematical Viscocity |
90mm2/s |
Impeller Cover |
Velox553/CI |
Impeller Cover |
Gunmetal |
Pumping Temperature |
0-60°C |
Shaft |
EN8 |
Shaft |
Teflon Coated/S.S.410 |
|
|
|
|
|
|
|
|
|
| |
| SPECIAL VERSIONS |
USED ON |
Avilable
- ON/OFF Rotary switch
- With flame proof motor for hazardous liquids
- For Frequent ON/OFF Cycles
- For Any Immersion depth
- For high viscous liquids
- To handle Hot Liquids upto 100 C
|
All lathes, Milling, CNC, retrofittings, EDM
wire and other conventional machines,
Cutting Machines, Printing machines Etc |
|
| |
|
|
| RV Series as per IS:2161 # Equivalent to other manufacturers Type 1 ^ Not as per IS:2161, Equivalent to other manufactures Type
2 + H2 Max is 50mm Extra RV25-@V160 available for single phase 230V 50Hz. Tank, pipeset available in standard sizes. |
|
| |
|
