RKM 100
MULTISTAGE COOLANT PUMPS RKM200 & RKM300
CONSTRUCTION OPTIONS APPLICATION
Body C.I. Stem Gunmetal Types of Fluids - Water
- Cooling Emulsion
- Cooling/Cutting Oils
Stem C.I. Impeller C.I. Kinematical Viscocity 45CST
Impeller Brass Impeller Cover Gunmetal/S.S. Pumping Temperature 0-50°C
Impeller Cover C.I. Shaft S.S.
Guide vane Noryl-30% GF Mechanical Seal SiC/SiC (for Grinding)
Shaft EN8 Bush/Sleeve SiC/SiC
Mechanical Seal Carbon/Ceramic
Bush/Sleeve Carbon/Carbon
SPECIAL VERSIONS USED ON

With Flame Proof Motors to pump hazardous liquids
With dual speed motor
Booster arrangement
Side suction arrangemen

 All CNC machines lathes and machining centres. Most suited for through tool cooling, deep hole drilling etc. Also suitable for Industrial washing, grinding Machine.
